Project Settings

projects represent an individual plant that a company operates they contain the edge devices needed for plant operations projects have separate team access privileges from the teams defined for companies settings the settings tab includes the project, timezone, and remove project sections project modify the project name, and add or modify the project description edge device data storage note this section is available for belden horizon data manager version 2 12 0 and later you have the option of storing edge device data in clickhouse you can store raw data or oma (open mobile alliance) data oma data oma data has been deprecated from belden horizon data operations and belden horizon data manager, but this option is available for backwards compatibility we recommend selecting raw data raw data we recommend using this option to visualize data in grafana, you must select raw data see docid\ z9jz9scseainfpb 4hjzj and docid\ ozlzfqdm9f w1gdoirdws to learn more edge devices backups note this section is available for belden horizon data manager version 2 12 0 and later configure the backup retention policy for edge devices by default, belden horizon data manager stores the three latest backups per edge device timezone select the time zone for your project you can remove the time zone and reselect the time zone note the recommended time zone selection is utc remove project remove the selected project removing a project cannot be undone important removing a project removes all related resources and they cannot be restored members the members tab includes the teams section teams select a company level team, including role, for the selected project the selections for a company level team are based on teams you added in the company teams section in company settings > company > company teams section the selections for a company level team are based on teams in the company teams section in docid\ ulfhddc4fjs6ihbthe3bz credentials the credentials tab includes the connection, mqtt server ssl certificate, web server ssl certificate, credentials, topics, and acl sections connection copy any of the server urls listed in the connection list mqtt server ssl certificate view, copy, or download the ssl certificate mqtt server certificate web server ssl certificate view, copy, or download the web server ssl certificate credentials add, copy, or remove a credential credentials are used for accessing wildcard and custom topics important save the password in a secure place as you cannot view the password again after you close the dialog box topics you can add, copy, and remove a custom topic you can copy a default topic there are three preloaded topics credentials to send the data to send request to receive responses acl you can add or remove an access control for a topic associated with the selected project message schema the message schema tab includes the json section from the json section, you can view and download the json schema of messages from devices that publish to the mqtt data topic https //technical openmobilealliance org/omna/lwm2m/lwm2mregistry html
