Events

you can view the events pane from a company or from an open project company events pane the company events pane allows you to select a start and end date for the events you want to view you can select an event type to filter the event list options are team/member, project, device, revoke, and all events you can add criteria in the filter field to further narrow the events list note the deactivation event type is available for belden horizon data manager version 2 18 0 and later access company events pane to access the events ui log in to belden horizon data manager select a company the projects pane appears from the navigation panel, select events the events pane appears refer to the following actions you can take on the events pane \[1] select start date \[2] select end date \[3] select event type company project device activation deactivation (available for belden horizon data manager version 2 18 0 and later) team team/member revoke grafana all events \[4] filter search by user or event \[5] refresh \[6] hide filter / show filter project events pane the project events pane includes system events the system events pane allows you to select a start and end date for the events you want to view you can select an event type to filter the event list you can also add criteria in the filter field to further narrow the events list the system events list includes a timestamp, type, user, and event message for each event edge devices events edge events allows you to view events for the entire date range over its life cycle you must enable event forwarding for the edge device note edgeevents is an experimental feature which must be enabled from the belden horizon data manager admin console before it becomes visible in belden horizon data manager see docid\ vtukwurugqxfmnrxufvmi for more information the trigger for events in edge devices will only work if the forward events toggle is enabled if this option is not activated, you won’t be able to see any logged events you'll only have access to the event logs after turning on this feature; otherwise, previous logs will remain inaccessible the edge devices events pane allows you to select and apply a start and end date for the events you want to view you can select options from the severity, component, edge device id filters to further narrow the entries you can filter a specific event by device or by component you can click the device id link, which navigates you to the selected edge device details pane in the events tab from the events tab in the edge device details pane, you can enable forward events this allows you to receive alerts when you use actions and triggers in the alerts module note belden horizon data operations events can be a source for belden horizon data manager alerts you can define triggers based on the belden horizon data operations events and get notifications access project events pane to access the project events pane log in to belden horizon data manager select a company the projects pane appears do one of the following click a project from the project pane the dashboard pane appears for the project click the actions icon for a project, and then select view the dashboard pane appears for the project from the navigation panel, select events the events pane appears by default, system events tab appears refer to the following actions you can take on the system events pane \[1] select start date \[2] select end date \[3] select event type company project device activation team team/member revoke grafana all events \[4] filter search by user or event \[5] hide filter / show filter \[6] swap between system events and edge devices events refer to the following actions you can take on the belden horizon data manager user ui's events edge device's events pane \[7] view edge device id docid\ mivpfpy64c43wuqdlploo \[8] view severity info \[9] view event info \[10] action menu filter by device you can further narrow the list by selecting a start and end date filter by component you can further narrow the list by selecting a start and end date \[11] show filter / hide filter expands / hides features \[16] \[22] \[12] select severity all info warning alert error \[13] select component all auth auth cc integrations dh device hub dm device management mp marketplace \[14] select edge device id displays all available connected devices \[15] select start date \[16] select end date
