Aveva Data Hub Integration Guide

review the following guide for setting up an integration between belden horizon data operations (bhdo) and aveva data hub once the integration is set up, you can send data and receive data through osisoft messaging format before you begin you must have access to https //datahub connect aveva com/ and have the correct admin permissions step 1 add a device follow the steps to docid\ t cwpe0 jsfw5 aoj8wpp the device will be used to store tags that will be eventually used to create outbound topics in the connector make sure to select the enable data store check box step 2 add tags after connecting the device in belden horizon data operations, you can docid\ wpe2hmxelarlbnhwbuchy to the device create tags that you want to use to create outbound topics for the connector step 3 create client in aveva data hub you will need to create a client credentials client and do the following set the role to tenant administrator copy the client secret for use later see the aveva data hub documentation https //docs aveva com/bundle/data hub/page/overview/get started/clients/gs client credentials clients html clients to learn more step 4 add type in aveva data hub add a type in aveva data hub to define the schema of the data coming from belden horizon data operations this allows aveva data hub to identify the payload and associate events with streams of data when you add the type, do the following select standard type enter values for id , name , and description add the following properties key id name base type select checkbox timestamp timestamp int64 select checkbox tagname tagname string select checkbox devicename devicename string success success boolean datatype datatype string value value string deviceid deviceid string description description string registerid registerid string see the aveva data hub documentation https //docs aveva com/bundle/data hub/page/add organize data/store data/types/types procedure html to learn more step 5 add stream in aveva data hub after adding the type, add a stream that will index data based on the properties of the type you created previously when you create the stream, select the type you created in step 2 see the aveva data hub documentation https //docs aveva com/bundle/data hub/page/add organize data/store data/streams/streams manage streams html to learn more step 6 add the aveva data hub connector in bhdo follow the steps to docid\ orxib vla2ngvdx94z1ow and select the aveva data hub provider configure the following parameters name enter a name for the connector description (optional) a description for the connector endpoint enter the appropriate regional endpoint (u s west, north europe, australia east), which can be found in aveva data hub by navigating to security > clients > client > connection information > regional endpoints u s west https //uswe datahub connect aveva com/ north europe https //euno datahub connect aveva com/ australia east https //auea datahub connect aveva com/ client id enter your aveva data hub client id, which can be found by navigating to security > clients > client > details > client id client secret enter your aveva data hub client secret, which can be copied when creating a client in step 1 if you need to create a new secret, navigate to security > clients > client > secrets tenant id enter your aveva data hub tenant id you can find it by navigating to security > client > details stream id enter the stream id you created in step 3 you can find it by navigating to data management namespace enter the namespace of the default sds stream name you can find it in the stream details throttling limit the maximum number of messages per second to be processed the default value is zero, which means that there is no limit persistent storage when enabled, this will cause messages to undergo a store and forward procedure messages will be stored within belden horizon data operations when cloud providers are online queue mode select the queue mode as lifo (last in first out) or fifo (first in first out) selecting lifo means that the last data entry is processed first, and selecting fifo means the first data entry is processed first step 7 enable the connector after adding the connector, click the toggle in the connector tile to enable it if you see a failed status, review the docid\ ocbqwycy xmmkwv9aunq and any relevant error messages after adding the connector in belden horizon data operations, you have the option of viewing the data flowing through the connector in aveva data hub or belden horizon data operations view data in aveva data hub you can view the stream data in aveva data hub create outbound topics for aveva data hub connector you will need to create outbound topics for the connector from the tags created in step 2 if there any existing inbound topics already created for the connector, disable them before creating the outbound topics to create outbound topics click the connector tile the connector dashboard appears click the topics tab click the import from devicehub tags icon the devicehub import dialog box appears select all the tags to import and click import after adding all required topics, navigate to the integration overview page and click the toggle to restart the connector and verify the status is connected enable topics to enable the topics, return to the topics tab and click the enable all topics icon view stream data in aveva data hub you can now view the data from the devicehub tag(s) in aveva data hub when you configure the stream data view, select get range values from the query type drop down list see the aveva data hub documentation https //docs aveva com/bundle/data hub/page/add organize data/store data/streams/streams view data html to learn more view data in belden horizon data operations you have the option of adding inbound topics in the aveva data hub connector, so that you can view data in the belden horizon data operations flows manager create inbound topic for aveva data hub connector you will use the stream id from aveva data hub to create the inbound topic if there any existing outbound topics already created for the connector, disable them before creating the inbound topic to create the inbound topic click the connector tile the connector dashboard appears click the topics tab click the add a new subscription icon configure the topic data direction select remote to local inbound local data topic (optional) paste the stream id value for the local data topic name a prefix will be automatically added to the name remote data topic copy the stream id you created in aveva data hub and paste it here description (optional) enter a description for the topic enable click the toggle to enable the topic click ok after adding all required topics, navigate to the integration overview page and click the toggle to restart the connector and verify the status is connected copy inbound topic name from the topics tab for the connector, copy the local topic name for the new topic and refer to it when creating the flow create flow you can now create the flow that will display the data from the connector to create the flow navigate to flows manager for a flows manager, click the go to flow definition icon the flow canvas opens in a new browser tab on the flow canvas, drag the datahub subscribe node and debug node onto the canvas then, connect the two nodes double click the datahub subscribe node the edit datahub subscribe node dialog box appears in the topic field, paste the inbound topic name you previously copied if needed, configure the datahub subscribe connection see the step 3 configure connector nodes section in docid 7x0n7c4dxswtd61vpibza to learn more optionally, add a name for the node click done , and then click deploy expand the message window beneath the flow to view debug messages click the debug icon confirm that messages are displaying in the message window
